Normal Diameter
mm/inch
Ø397MM/15 IN
Nominal Impedance
Ohm
8 Ω
Power Capacity
Watt
600W
Sensitivity 1W(/1M)
dB
97dB
Frequency Range
Hz
51Hz-2000Hz
Voice coil Diameter
mm
Ø100.5 mm
Magnet Dimension
mm
Ø220*25 mm
Resonant Frequency
FS
51Hz
D.C. Voice Coin Resistance
Re
5.7Ω
Mechanical Quality Factor
Qms
6.33
Electrical Quality Factor
Qes
0.51
Total Quality Factor
Qts
0.48
Equivalent Air voloum to CMS
Vas
231.72L
Mechanical Compliance
Cms
9.5e-03 m/N
Mechanical Resistance
Rms
6.82 Ns/m
BL Factor
BL
22.09
