Nominal Diameter
15 Inch
Rated Impedance
8 ohm
Power Handling capacity
600 Watts
Sensitivity 1W, 1M
96.5 db
Effective Piston Diameter
394 mm
Voice coil Diamater
99.5 mm
Resonate Frequency
fs
45 Hz
DC Resistance
Re
5.3
Mechanical Q Factor
Qms
14
Electrical Q Factor
Qes
0.4
Total Q Factor
Qts
0.38
BL Factor
BL
22 T. M
Effective Moving Mass
Mms
130gr
Equivalent Cas Air Load
Vas
107 Liters
Effettive Piston Area
Sd
0.0908M2
Half Space Efficiency
Eff
2.20% %
Voice Coil Height
Hvc
12mm
Airgap Height
Hag
21mm
Voice Coil Over- Hung
Xmax
4.5mm
Basket
Aluminium
Magnet Type, Size OD X ID X H
220*110*25
Voice Coil Former
Glass Fiber Polymide
Voice Coil Material
Copper Round
Cone Material
Pulp Paper
Surround
Treated Cloth
Spider
Cotton Blend Polyester
Dust Cap
Pulp Paper
