Nominal Diameter
15 Inch
Rated Impedance
8 ohm
Power Handling Capacity
600 Watts
Sensitivity 1W, 1M
96.7 db
Effective Piston Diameter
387 mm
Voice Coil Diameter
99.5 mm
Resonate Frequency
fs
50 Hz
DC Resitance
Re
5.8
Mechanical Q Factor
Qms
15
Electrical Q Factor
Qes
0.62
Total Q Factor
Qts
0.6
BL Factor
BL
16.2 T.M
Effective Moving Mass
Mms
95gr
Equivalent Cas Airload
Vas
100 Liters
Effective Piston Area
Sd
0.0881 M2
Half- Space Efficiency
Eff
2.10 % %
Voice Coil Height
Hvc
10 mm
Airgap Height
Hag
20 mm
Voice Coil Over- Hung
Xmax
5 mm
Basket
Aluminium
Magnet Type, Size OD*ID*H
220*110*22
Voice Coil Former
Kepton
Voice Coil Material
Aluminium flat
Cone Material
Pulp Paper
Surround
Treated Cloth
Spider
Cotton Blend Polyster
Dust Cap
Pulp Paper
