Nominal Diameter
15 inch
Rated Impedance
8 Ohm
Power Handling Capacity
1000 Watts
Sensitivity 1 W,1 M
96.3 db
Effective Piston Diameter
393 mm
Voice Coii Diameter
99.5 mm
Resonate Frequency
fs
50 Hz
DC Resitance
Re
5.2
Mechanical Q Factor
Qms
7.2
Electrical Q Factor
Qes
0.45
Total Q Factor
Qts
0.43
BL Factor
BL
21.5 T .M
Effective Moving Mass
Mms
96 gr
Equivalent Cas Air Load
Vas
92 Liters
Effective Piston Area
Sd
0. 0889 M2
Half- Space Efficiency
Eff
2.40% %
Voice Coil Height
Hvc
8mm
Airgap Height
Hag
18mm
Voice Coil Over -Hung
Xmax
5mm
Basket
Alluminium
Magnet Type, Size Od * ID* H
220*110*20
Voice Coil Former
Glass Fiber Polymide
Voice Coil Material
Copper round
Cone Material
Pulp Paper
Surround
Treated Cloth
Spider
Cotton Blend Polyester Double
Dust Cap
Pulp Paper
